Automatic Transmission, RWD, 5 Forward Speeds + Reverse
This is a cut-away of an automatic transmission with RWD, and it is carefully sectioned for training purposes. Colors are used to differentiate between parts. Many parts have been chromium plated and galvanized for a longer life. An exploded/cut-away view of the hydraulic circuit to better show its various ducts and valves. This transmission is operated manually and is mounted on a stand with wheels.
SPECIFICATIONS:
• RWD
• 5 forward speeds + reverse
• Casing
• Torque converter
• Oil pump
• Stationary plate clutch
• Rotary Plate clutch
• Planetary gear train
• Hydraulic circuit valve
• Centrifugal regulator
• Mounted on stand with wheels
• Operated manually
WEIGHT AND DIMENSIONS:
Size: 90cm x 60cm x 100cm (L x W x H)
Net Weight: 60 kg
Gross Weight: 85 kg
Product Name | Automatic Transmission, RWD, 5 Forward Speeds + Reverse |
---|---|
PDF Downloads | Product Sheet for N98-ND11060 |
