Multipoints FIAT Engine with Electronic Injection and Gas/LPG Feeding System

This is an accurate cut-away of a FIAT engine with the main components of two different feeding circuits (gas and LPG).

This is an accurate cut-away of a FIAT engine with the main components of two different feeding circuits (Gas and LPG).

GAS FEEDING CIRCUIT SPECIFICATIONS
• Electro-Injectors
• Throttle Body
• Rail
• Sensors / Phonic Wheel
• Lambda Probe
• Electronic Ignition

LPG FEEDING CIRCUIT SPECIFICATIONS
• Genius Reducer
• LPG Electrovalve
• LPG Tank with Float Device for the Charge Level
• Charge Socket
• Filter
• Rail and LPG Electro-Injectors

ENGINE SPECIFICATIONS
Fiat engine – 4 cylinders – 8 valves
• Displacement 1242 cc
• Bore and stroke 70,8 x 78,8
• Overhead camshaft (OHC)
• Electronic injection, IAW Weber Marelli Multipoints (MPI)
• Electronic ignition
• Toothed belt
• 12V Alternator
• Oil Pump
• Operates manually via hand crank
• Mounted on a stand with wheels

WEIGHT AND DIMENSIONS:
Size: 70cm x 80cm x 95cm (L x W x H)
Net Weight: 86 kg
Gross Weight: 120 kg
