Name Electronic Injection Multipoints System Panel

Electronic Injection Multipoints System Panel

SKU: N98-ND9900

Availability: In stock

ASK FOR QUOTE
Add Items to Cart Add To Cart   Add to Quote

Be the first to review this product

This trainer shows the functioning of a multi-point electronic injection system. It is mounted on a sturdy stand with wheels and easily allows you to:

• Regulate, by use of a pedal, the rpm from 0 to 2400.

• Effortlessly simulate the air pressure sensor in the collector as well as the water temperature.

• Generate sensor and actuator faults by disrupting the relative connections interface (standard with K line and 7 pins).

• Conveniently use and display this model because of its compact and inclusive design.

SPECIFICATIONS:
• Fuel Tank
• Fuel electro-pump
• Inlet fuel piping
• Electronic ECU injection-ignition
• Battery
• Feeding contractor system
• Fuel steams electro-valve
• Protection fuse of the injection-ignition system
• Activated carbon filter
• Diagnostic socket
• Absolute pressure and temperature sensor
• Rpm and PMS sensor
• Ignition spark plugs
• Cooling liquid temperature sensor
• Electro-injectors
• Positioning butterfly valve sensor
• Minimum rpm actuator
• Ignition coils
• Lambda probe (upstream)
• Lambda probe (downstream)
• Injection phase sensor
• On-off switch
• Feeding collector fuel
• OBD2 socket connection

WEIGHT AND DIMENSIONS
Size: 140cm x 70cm x 210cm (L x W x H)
Net Weight: 96 Kg
Gross Weight: 170 Kg
