Name Electronic Single-Point Injection System
Dimensions No

Electronic Single-Point Injection System

SKU: N98-ND9901

Availability: In stock

ASK FOR QUOTE
Add Items to Cart Add To Cart   Add to Quote

Be the first to review this product

This trainer is an electronic teaching aid designed to show the functioning of an electronic ignition system. This panel is mounted on a sturdy stand with wheels and allows you to easily:

• Regulate the RPM's from 0 to 2000 with the use of an attached pedal.

• Educate about the IAW Weber-Marelli single-point injection, self-contained engine management system, which controls both the fuel injection and ignition.

• Demonstrate to your students an entire fuel injection system comprised of: fuel tank, an electric fuel pump, a fuel filter, fuel supply and return lines, a throttle body with electronic fuel injector, an Electronic Control Unit (ECU), as well as the associated sensors, actuators and wiring.


SPECIFICATIONS:
• Fuel tank
• Fuel pump
• Fuel pressure regulator
• Injector
• Fuel vapour trap
• Idle stepper motor
• Absolute pressure sensor
• Injection/ignition ECU
• Throttle position sensor
• Engine coolant temperature sensor
• Intake air temperature sensor
• Injection/ignition duel relay
• Ignition coils
• Rpm and TDC sensor
• Spark plugs
• Diagnostic socket
• EVAP solenoid
• Lambda /oxygen sensor


WEIGHT AND DIMENSIONS:
Size: 140cm x 70cm x 210cm (L x W x H)
Net Weight: 96 kg
Gross Weight: 170 kg
