V6 Gas Engine with Carburetor - Electrical Operation
This product is a cut-away of a V6 gas engine with twin-body carburetor. It is carefully sectioned for training purposes and professionally painted with different colors to better differentiate the various parts, cross-sections, lubricating circuits, fuel system, cooling system, and other key components. The engine operates electrically at 120 volts and runs at a reduced speed to allow students to be able to easily understand and observe the operation of the various mechanical parts. Many parts have been chromium plated and galvanized for a longer life. It operates electrically, and it is mounted on a stand with wheels.
SPECIFICATIONS:
• V6
• Displacement: 2,800/3,200cc
• Single Overhead camshaft SOHC (1 cam per head)
• Twin barrel carburetor
• Centrifugal water pump
• 12 volt alternator
• Membrane clutch
• Operates electrically at 120 volts
• Mounted on stand with wheels
WEIGHT AND DIMENSIONS:
Size: 120cm x 60cm x 100cm (L x W x H)
Net Weight: 190 kg
Gross Weight: 260 kg
Product Name | V6 Gas Engine with Carburetor - Electrical Operation |
---|---|
PDF Downloads | Product Sheet for N98-ND5190 |
