Turbo Diesel Truck Engine, Inline 6, with Intercooler

This product is an electronically controlled cut-away of a turbo diesel truck engine with an inline 6- cylinder configuration, direct injection, and intercooler. This cut-away allows you to:

• Use at a reduced operating speed to teach about all of the moving mechanical parts.
• Point to each of its carefully sectioned parts to train your students.
• Easily differentiate between the color-coded cross-sections, lubricating system, cooling system, fuel system, etc.
• Easily display and move the cut-away thanks to its sturdy stand and wheels.

SPECIFICATIONS:
• 4-Stroke engine; Inline-6
• Displacement: 5,200cc
• Direct injection
• Bosch type in-line injection pump with mechanical governor
• Air/air Intercooler
• Camshaft in the crankcase
• Spring single-plate clutch
• Turbocharged
• Gearbox: 4 forward speeds + reverse
• Gear distribution
• Operates electrically at 120 volts
• Mounted on stand with wheels

WEIGHT AND DIMENSIONS:
Size: 90cm x 180cm x 170cm (L x W x H)
Net Weight: 450 kg
Gross Weight: 560 kg
