This apparatus is generally used with the
GENECON generator to examine the relationship between Voltage, Current, and Resistance within electrical circuits. Students are capable of clearly defining and explaining resistance using the enclosed
wire. Additional experiments can be performed by combining this set with either a
DC Ammeter or
Voltmeter.
SPECIFICATIONS -Wooden Stand: Varnished plywood with terminal (500x40x12mm)
-Resistance Wire: Nichrome wire (0.2x470mm)
-Accessories:
Long wire lead with socket and clips-Miniature bulb (3.8V, 300mA)
-Spare Nichrome wire (0.2x470mm)
