Name Heavy-Duty Truck Rear Axle with Locking Differential
Dimensions No

Heavy-Duty Truck Rear Axle with Locking Differential

SKU: N98-ND11198

Availability: In stock

ASK FOR QUOTE
Add Items to Cart Add To Cart   Add to Quote

Be the first to review this product

This product is a cut-away of a Heavy-duty Truck Rear Axle with Locking Differential. It is mounted on a sturdy stand with wheels and it is operated manually by hand crank.


SPECIFICATIONS:
• Complete section of the rear axle
• Bevel gear (pinion - crown)
• Differential (satellite and planetary)
• Axle shafts
• Reducer and planetary on the hub
• Brakes with jaws/drum
• Double air brake element
• Mounted on stand with wheels
• Operated manually by hand crank


WEIGHT AND DIMENSIONS:
Size: 241cm x 103cm x 106cm (L x W x H)
Net Weight: 600 kg
Gross Weight: 746 kg
