Gas Engine for Assembly and Disassembly
Students can work individually or in small groups performing a complete engine disassembly, inspection, measurement, and reassembly. The engine is mounted on a sturdy engine stand with a locking gear reduction rotating system.
ASE Task: A1.A.6 - Verify engine mechanical timing.
ASE Task: A1.B.1 - Identify cylinder head and valve train components and configurations.
ASE Task: A1.B.2 - Remove; inspect gasket; install cylinder head.
ASE Task: A1.B.3 - Clean and visually inspect a cylinder head/gasket.
ASE Task: A1.C.1 - Identify engine block components and configurations.
Students can work individually or in small groups performing a complete engine disassembly, inspection, measurement, and reassembly. The engine is mounted on a sturdy engine stand with a locking gear reduction rotating system.
SPECIFICATIONS
• Modern gas engine
• Rotating stand
• Overhauled front-wheel drive engine
• 4-Stroke
• Displacement: 1242 cc
• 4-Cylinders in-line with overhead camshaft, two valves per cylinder
• Timing system, working with toothed belt
• Electronic ignition with 4 spark plugs
• Electronic injection
• Alternator
• Lubrication system with mechanical oil pump
• Oil filter & Flywheel
• Clutch, mechanical dry, single disc type
• Optional: 219-Piece Toolbox (extra)
WEIGHT AND DIMENSIONS
Size: 106cm x 89cm x 136cm (L x W x H)
Net Weight: 124kg
Gross Weight: 188kg
| Product Name | Gas Engine for Assembly and Disassembly |
|---|---|
| PDF Downloads | Product Sheet for N98-ND9000 |
