Braking System Panel, Dual Circuit
This trainer represents a dual circuit braking system. The trainer is mounted on a panel.
ASE Task: A5.A.2 - Identify brake system components and configurations.
ASE Task: A4.B.3 - Check master cylinder for internal/external leaks and proper operation; determine needed action.
This trainer represents a dual circuit braking system. The trainer is mounted on a panel and allows you to:
• Describe the operating parts of the braking system, which have been carefully sectioned to allow a clear view.
• Manually operate the system with a hydraulic pump connected to the disk brake and the drum brake.
• Avoid rear-wheel lock up during the braking phase with a braking adjuster positioned between the pump and the rear drum brake.
• Effortlessly use and display this model because of its compact and inclusive design.
WEIGHT AND DIMENSIONS:
Size: 110cm x 60cm x 40cm (L x W x H)
Net Weight: 35 Kg
Gross Weight: 65 Kg
| Product Name | Braking System Panel, Dual Circuit |
|---|---|
| PDF Downloads | Product Sheet for N98-ND12050 |
